Description
Traditionally, paring the proper fuel level level gauge to the application could be a more difficult task than it needed to be. The AutoMeter Digital Stepper Motor Fuel Level Gauge drastically simplifies the process with it’s easily configurable resistance range. With 7 common configurations stored in memory from the factory, the vast majority of all applications are covered. In the instance your fuel level sender is not included in these preconfigured ranges, an innovative custom calibration mode allows any sending unit that operates between 0 and 280 ohms, empty or full, to be easily paired. Our “snapshot” programming method will allow you to capture the empty and full readings and the gauge does the rest. No matter your application, there simply isn’t an easier solution for fuel level monitoring available on the market. A direct plug in wiring harness is included for ease of installation.
Resources
Installation Instructions
Specifications:
| Add-On | N/A |
| Analog Or Digital | Analog |
| Bezel Color | Black |
| Bezel Style | Super Bezel |
| Block Adapter Included | No |
| Bulb and Socket Number | 3220 |
| Bulb Technology | Incandescent |
| Description_ASC | PHANTOM |
| Description_DEF | Fuel Level Gauge |
| Description_DES | GAUGE, FUEL LEVEL, 2 1/16″, 0-280O PROGRAMMABLE, PHANTOM |
| Description_DES | GAUGE; FUEL LEVEL; 2 1/16in.; 0-280O PROGRAMMABLE; PHANTOM |
| Description_EXT | 2-1/16in. FUEL LEVEL; PROGRAMMABLE 0-280 O; PHANTOM |
| Description_EXT | Traditional incandescent lighting illuminates around the perimeter of the dial |
| Description_FAB | 12 and 16 volt compatible, compatible with nearly every street car or race car electrical system |
| Description_FAB | 12 And 16V Compatible |
| Description_FAB | Adjustable Scale w/ 7 preset ranges for common vehicle types (73E/10F, 16E/158F, 0E/30F, 0E/90F, 240E/33F, 107.5E/7F, 131E/12F) |
| Description_FAB | Autometers Race Proven Digital Stepper Motor Electric Instruments Provide Unmatched Accuracy Which Is Further Increased By Utilizing A Self Calibration Sequence During Power Up |
| Description_FAB | Digital Stepper Motor Provides Unmatched Accuracy |
| Description_FAB | Gauge kit includes 20 ft. wiring harness, bulb and socket assembly, red and green bulb covers, mounting hardware, and detailed instructions for installation |
| Description_FAB | Incandescent Lighting Illuminates Around Perimeter Of Dial |
| Description_FAB | Incl. 20 ft. Wiring Harness |
| Description_FAB | Incl. Bulb/Socket Assembly/Red And Green Bulb Covers |
| Description_FAB | Incl. Mounting Hardware/Instructions |
| Description_FAB | Traditional incandescent lighting illuminates around the perimeter of the dial |
| Description_FAB | User Definable Resistance Between 0-280 Ohms |
| Description_FAB | User definable resistance setting programmable anywhere between 0-280 ohms |
| Description_INV | 2-1/16″ FUEL LEVEL, E-F, FSE, PHANTOM |
| Description_INV | 2-1/16in. FUEL LEVEL; E-F; FSE; PHANTOM |
| Description_LAB | Made In Logo |
| Description_LAB | Proposition 65 |
| Description_MKT | Traditionally, paring the proper fuel level level gauge to the application could be a more difficult task than it needed to be. The AutoMeter Digital Stepper Motor Fuel Level Gauge drastically simplifies the process with it’s easily configurable resistance range. With 7 common configurations stored in memory from the factory, the vast majority of all applications are covered. In the instance your fuel level sender is not included in these preconfigured ranges, an innovative custom calibration mode allows any sending unit that operates between 0 and 280 ohms, empty or full, to be easily paired. Our “snapshot” programming method will allow you to capture the empty and full readings and the gauge does the rest. No matter your application, there simply isn’t an easier solution for fuel level monitoring available on the market. A direct plug in wiring harness is included for ease of installation. |
| Description_MKT | Traditionally, Paring The Proper Fuel Level Level Gauge To The Application Could Be A More Difficult Task Than It Needed To Be. The Autometer Digital Stepper Motor Fuel Level Gauge Drastically Simplifies The Process With Its Easily Configurable Resistance Range. With 7 Common Configurations Stored In Memory From The Factory, The Vast Majority Of All Applications Are Covered. In The Instance Your Fuel Level Sender Is Not Included In These Preconfigured Ranges, An Innovative Custom Calibration Mode Allows Any Sending Unit That Operates Between 0 And 280 Ohms, Empty Or Full, To Be Easily Paired. Our Snapshot” Programming Method Will Allow You To Capture The Empty And Full Readings And The Gauge Does The Rest. No Matter Your Application, There Simply Isnt An Easier Solution For Fuel Level Monitoring Available On The Market. A Direct Plug In Wiring Harness Is Included For Ease Of Installation. |
| Description_SHO | 2-1/16″ FUEL LEVEL, |
| Description_SHO | 2-1/16in. FUEL LEVEL |
| Electric Or Mechanical | Electric |
| Face Color | White |
| Fuel Line Adapter Included | No |
| Gauge Adapter Included | No |
| Gauge Size | 2.0625 in. |
| Gauge Size | 52.4mm |
| Gauge Type | Fuel Level |
| height | 4.5 |
| Hole Size | 0.0625 in. |
| Hole Size | 52.4mm |
| Illuminated | Yes |
| length | 4.75 |
| Lens | Flat Clear |
| Light Covers Number | 3244/3215 |
| Lighting Color | White Incandescent |
| Lighting Type | Incandescent |
| Liquid Filled | No |
| LTL | N |
| Mounting Bracket Number | 2230 |
| Movement Type | Electric Digital Stepper Motor |
| Number Color | Black |
| Outer Bezel Diameter | 2.250 in. |
| Pointer Color | Fluorescent Red |
| Size | 2.3125 in. |
| Sweep | Full |
| Title | 2-1/16 in. FUEL LEVEL, PROGRAMMABLE 0-280 O, PHANTOM |
| Voltage | 8-18 V |
| WARNING CA Proposition 65 | Yes |
| WARNING CA Proposition 65 Message | Warning: This product can expose you to chemicals; which are known to the State of California to cause cancer. For more information; visit www.p65warnings.ca.gov. |
| weight | 0.6 |
| width | 4.25 |
| Wire Harness Number | 5233 |
