Shakespeare AIS 4-Foot Phase III Antenna for Marine Automatic Identification Systems

Description

PHASE III 6396-AIS-R 4′ AIS Antenna 3dB Gain
Specially engineered for the extra bandwidth required by AIS transceivers, this Phase IIIT antenna enables reliable communication over marine VHF frequencies.

• Silver-plated outer conductor, copper inner conductor
• Stainless steel mounting sleeve
• SO-239/PL-259 connector

Specifications

• Max. Power Input: 50 watts
• SWR: Less than 1.5:1 at 162 MHz
• Bandwidth: 5 MHz within 2.0:1 VSWR
• Frequency: VHF AIS Marine Band
• DC Grounding: Yes
• Pattern: Omnidirectional
• Polarization: Vertical

Specifications:

• Length (Inches): 48″
• Construction: Fiberglass
• Color: White
• Antenna Band: AIS
• Box Dimensions: 2″H x 2″W x 58″L WT: 2 lbs
• UPC: 719441200688
